Key Features CPU and Chipset Socket: LGA1851, supporting Intel® Core™ Ultra processors. Chipset: Intel® Z890 Express Chipset. L3 Cache: Varies based on the installed CPU. Memory Type: DDR5 (Up to 9500MT/s overclocked). Capacity: Up to 256 GB (64 GB per DIMM). Architecture: Dual channel. Features: Supports ECC (non-ECC mode) and non-ECC unbuffered DIMMs. Extreme Memory Profile (XMP) supported. CUDIMM module support. Onboard Graphics Integrated Graphics: Intel® HD Graphics (dependent on CPU). Display Outputs: Thunderbolt™ 4: Up to 5120×2880@60Hz. USB Type-C®: Up to 3840×2160@240Hz. HDMI: Up to 1920×1080@30Hz. Supports up to three displays simultaneously. Audio Chipset: Realtek® ALC1220 with ESS ES9118 DAC. Features: DTS:X® Ultra, S/PDIF Out. High-definition audio with customizable audio jack functions. Networking Wired LAN: Marvell® AQtion AQC113C 10GbE. Wireless: Intel® Wi-Fi 7 (6 GHz support) and Bluetooth 5.4. Requires Windows 11 SV3 for Wi-Fi 7. Expansion Slots PCIe Slots: 1 x PCIe 5.0 x16 (CPU-dependent). 2 x PCIe 4.0 slots (x4 and x1). Storage M.2 Slots: 5 total, supporting PCIe 5.0/4.0 and SATA drives. SATA Ports: 4 x 6Gb/s connectors. RAID Support: RAID 0/1/5/10 for both NVMe and SATA. USB Thunderbolt™ 4: 2 ports (USB4 support up to 40Gbps). USB Type-C®: Internal Gen 2×2 header. Total Ports: USB 3.2 Gen 2 (6 ports). USB 3.2 Gen 1 (8 ports). USB 2.0/1.1 (6 ports). Internal I/O Connectors Supports extensive connectivity with multiple headers for fans, RGB strips, USB, temperature sensors, and more. Unique Features Cooling Support: Multiple fan and water pump headers with speed control. GIGABYTE Control Center (GCC): Manage system functions, updates, and features. Q-Flash and Q-Flash Plus: Easy BIOS updates without a CPU or memory. Operating System and Form Factor OS Support: Windows 11 64-bit. Form Factor: ATX (30.5cm x 24.4cm).
