�� Specifications ⚡ CPU & Chipset Socket LGA 1700 – Supports Intel 14th, 13th & 12th Gen Core™ Processors Intel B850 Express Chipset ⚡ Memory Supports DDR5 8600(O.C.) / 8400(O.C.) / 8200(O.C.) / 8000(O.C.) / 7800(O.C.) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000MT/s and lower 4 x DDR5 DIMM slots, up to 192GB (48GB per DIMM) Dual-channel architecture Intel XMP & AMD EXPO support ⚡ Graphics & Display Integrated Intel UHD Graphics support (with compatible CPUs) 1 x HDMI 2.1 port – Max resolution: 4096×2160 @ 60Hz 1 x DisplayPort 1.4 – Max resolution: 7680×4320 @ 60Hz ⚡ Audio Realtek ALC897 CODEC – High-Definition Audio 7.1-channel audio output ⚡ Networking Wi-Fi 7 (802.11be) & Bluetooth 5.4 Realtek 2.5GbE LAN ⚡ Expansion Slots 1 x PCIe 5.0 x16 slot (CPU) 1 x PCIe 4.0 x16 slot (x4 mode, chipset) 1 x PCIe 3.0 x1 slot (chipset) ⚡ Storage 3 x M.2 Slots: 1 x PCIe 5.0 x4 M.2 (CPU) – 25110/2280 2 x PCIe 4.0 x4 M.2 (Chipset) – 22110/2280 4 x SATA 6Gb/s ports RAID 0, 1, 10 support ⚡ USB Connectivity Rear Panel: 1 x USB4 Type-C (40Gbps, DP Alt Mode, PD Support) 1 x USB 3.2 Gen 2×2 Type-C (20Gbps) 3 x USB 3.2 Gen 2 Type-A (10Gbps) 4 x USB 3.2 Gen 1 Type-A (5Gbps) 2 x USB 2.0 ports Internal: 1 x USB 3.2 Gen 2 Type-C (10Gbps) header 1 x USB 3.2 Gen 1 header (supports 2 USB ports) 2 x USB 2.0 headers (supports 4 USB ports) ⚡ Internal I/O 24-pin ATX power, 2 x 8-pin ATX 12V power 1 x CPU fan header, 1 x CPU water pump header 4 x system fan headers, 3 x ARGB headers, 1 x RGB header 3 x M.2 slots, 4 x SATA ports 1 x front panel header, 1 x front panel audio header 1 x USB Type-C 3.2 Gen 2 header, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0 headers 1 x reset jumper, 1 x TPM header 2 x temperature sensor headers ⚡ Rear I/O Panel 1 x Q-Flash Plus button 1 x HDMI 2.1 1 x DisplayPort 1.4 1 x USB4 Type-C (40Gbps, DP Alt Mode, PD Support) 1 x USB 3.2 Gen 2×2 Type-C (20Gbps) 3 x USB 3.2 Gen 2 Type-A (10Gbps) 4 x USB 3.2 Gen 1 Type-A (5Gbps) 2 x USB 2.0 1 x 2.5GbE LAN (RJ-45) 3 x audio jacks Wi-Fi 7 antenna connectors ⚡ Software & Features GIGABYTE Control Center (GCC) Q-Flash & Q-Flash Plus support Smart Backup & RGB Fusion ⚡ BIOS 256Mbit AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 ⚡ OS Support Windows 11 64-bit ⚡ Form Factor ATX – 30.5cm x 24.4cm
