Gigabyte X870E AORUS ELITE WIFI7 1.1

�� Processor & Chipset CPU Socket: AMD AM5 Compatible CPUs: Ryzen™ 9000 / 8000 / 7000 Series Chipset: AMD X870E �� Memory Support 4 × DDR5 DIMM Slots, Dual Channel Up to 256GB, speeds up to DDR5-8200(OC) AMD EXPO™ & Intel XMP profile support Non-ECC, unbuffered DIMMs �� Graphics Outputs USB4 Display Output: 2 × USB4® Type-C, DP 1.4, up to 3840×2160@240Hz HDMI Ports: Rear HDMI 2.1: 4096×2160@60Hz Front HDMI 1.4: 1920×1080@30Hz Supports up to 4 displays �� Audio Realtek® ALC1220 Codec Supports 7.1 Surround Sound & DSD Audio Optical S/PDIF Out �� Networking Realtek® 2.5GbE LAN Wi-Fi 7 Bluetooth 5.4 MediaTek MT7925 (rev. 1.0) or Realtek RTL8922AE (rev. 1.1/1.2) Windows 11 SV3 required for full Wi-Fi 7 features ⚙️ Expansion Slots 1 × PCIe 5.0 x16 (CPU) Shared bandwidth with M2B/M2C – drops to x8 when populated 1 × PCIe 4.0 x4 (Chipset) 1 × PCIe 3.0 x4 (Chipset) �� Storage Options M.2 Slots: 1 × PCIe 5.0 x4 (M2A_CPU, up to 25110) 2 × PCIe 5.0 x4 (M2B/M2C_CPU, 22110/2280) – Disabled with Ryzen 8000 Phoenix CPUs 1 × PCIe 4.0 x4 (M2D_SB, Chipset) SATA: 4 × SATA 6Gb/s NVMe RAID 0/1/5/10 (RAID 5 for Ryzen 9000 only) SATA RAID 0/1/10 �� USB Connectivity Rear Panel: 2 × USB4® Type-C 2 × USB 3.2 Gen 2 (Type-A) 4 × USB 3.2 Gen 1 4 × USB 2.0 Internal Headers: USB 3.2 Gen 2×2 (Type-C) 7 × USB 3.2 Gen 1 (1 rear, 6 internal) 8 × USB 2.0 (4 rear, 4 internal) �� Cooling & RGB 1 × CPU Fan 1 × Pump Header 4 × Chassis/System Fan Headers 3 × Addressable RGB Gen2 1 × RGB Header ��️ Extras & Features Q-Flash & Q-Flash Plus BIOS Update Onboard Power & Reset Buttons TPM header, Clear CMOS GCC Software Suite Windows 11 64-bit support only ATX (30.5 × 24.4 cm)
