Brand Name SilverStone Technology Compatible Devices Personal Computer Connector Type ATX Output Wattage 600 Form Factor ATX Wattage 1200 watts Cooling Method Air Item Dimensions 15 x 15 x 8.6 centimeters Power Supply Design Full Modular System Bus Connector Type 4 Pin About this item Equipped with Gen5 12VHPWR PCIe connector, meeting Intel ATX 3.0 specification standard Cybenetics Platinum efficiency certification 24/7 continuous power output with 50℃operating temperature Fully Modular design All Japanese electrolytic capacitors Ultra silent 135mm FDB fan with semi-fanless function Product No. SST-HA1200R-PM Color Black (lead-free paint) Power density 620W per liter Combined 12V 1200W Input Frequency Range 47Hz ~ 63Hz Efficiency Greater than equal to 87% & <89% overall efficiency Operating temperature 0°C ~ 50°C Noise Level 0 dBA minimum Model (safety certification) SST-AX1200MCPT-A Max. DC Output 1200W Combined 3.3V & 5V 120W Input Voltage 90 ~ 264 Vrms PFC Active PFC (PF>0.9 at full load) MTBF 100,000 hours Cooling System Silent 11mm FDB fan Certification Cybenetics Platinum Load Range Output 3.3V 5V 12V 5VSB -12V Max.(Amps) 24A 24A 108.3A 2.5A 0.3A Min.(Amps) 0A 0A 0A 0A 0A Range (%) ±3% ±3% 5/-7% ±5% ±5% Line Reg.(%) ±1% ±1% ±1% ±1% ±1% Ripple(mVp-p) 30mV 30mV 70mV 40mV 80mV
