�� Key Features 80 PLUS® Platinum Certified: Maximum power efficiency, minimal waste Fully Modular UltraFlex™ Cables: Flexible, flat, and easy to route FDB Fan with Zero RPM Mode: 140 mm Fractal Design Dynamic Series fan with semi-passive operation Premium Build: 100% Japanese capacitors ensure longevity and stability Wide Thermal Range: Operates at up to 50°C under full load �� Comprehensive Protection Suite Over Voltage Protection (OVP) Under Voltage Protection (UVP) Over Power Protection (OPP) Short Circuit Protection (SCP) Over Current Protection (OCP) Over Temperature Protection (OTP) �� Connector Configuration Connector Type Quantity Length / Configuration ATX 24-pin 1 600 mm EPS 4 Plus4 pin / 8-pin 2 700 mm / 600 mm PCIe 6 Plus2 pin 6 550 Plus 120 mm SATA 10 400 Plus150 Plus150 Plus150 mm & 650 Plus150 mm Peripheral (Molex) 4 400 Plus150 Plus150 Plus150 mm �� Specifications Input Voltage: 100–240V AC Input Frequency: 50–60 Hz Current: 10A / 5A DC Output: 3.3V / 5V: 22A each (Combined 120W) 12V: 71.6A (859.2W) -12V: 0.3A Plus5Vsb: 3A Total Power Output: 860W Standby Efficiency: ErP 2013 (<0.45W @ 230V AC) Sleep State: C6/C7 compliant �� In the Box Ion Platinum 860W PSU Modular cable kit (in storage bag) PSU storage bag Velcro cable ties & mounting screws AC power cord User guide Red note included in packaging �� Dimensions & Weight PSU Dimensions (LxWxH): 150 x 150 x 86 mm Net Weight: 2.53 kg Package Dimensions: 325 x 210 x 110 mm Gross Weight: 3.06 kg ✅ Certifications CE, FCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, KC PlusKCC, RoHS, WEEE �� Product Codes Product Code: FD-P-IA2P-860 EAN: 7340172702887 UPC: 843276102883 JAN: 4537694282734
