Xpg Core Reactor II 1200W 80 Plus Gold Full Modular

Power Supply Specifications (650W–1200W Series) Dimensions (L x W x H) 650W–850W: 140 x 150 x 86 mm 1000W–1200W: 160 x 150 x 86 mm Cybenetics Rating 1200W: Platinum 1000W: Platinum 850W: Platinum 750W: Platinum 650W: Platinum 80 Plus Rating GOLD ATX Version ATX 3.1 Protections OCP | OVP | OPP | OTP | UVP | SCP | NLO | SIP Certification CE | CB | FCC (IC) | TUV | cTUVus | TUV S-Mark | NOM | BSMI | UKCA | EAC | CCC | RCM PFC 0.99 Input Voltage 100 – 240V Input Current 1200W: 15A 1000W: 13A 850W: 12A 750W: 10A 650W: 10A Input Frequency 47 – 63 Hz (all models) DC Output Voltage 5V | 3.3V | 12V | -12V | 5Vsb Total Output 1200W: 5V/ 3.3V: 22A | 12V: 100A | -12V: 0.3A | 5Vsb: 3A 1000W: 5V/ 3.3V: 22A | 12V: 83.5A | -12V: 0.3A | 5Vsb: 3A 850W: 5V/ 3.3V: 22A | 12V: 70.8A | -12V: 0.3A | 5Vsb: 3A 750W: 5V/ 3.3V: 22A | 12V: 62.5A | -12V: 0.3A | 5Vsb: 3A 650W: 5V/ 3.3V: 20A | 12V: 54.1A | -12V: 0.3A | 5Vsb: 3A Power Excursion 1200W: 2820W (up to 235% for 100μs) 1000W: 2350W (up to 235% for 100μs) 850W: 1997W (up to 235% for 100μs) 750W: 1762W (up to 235% for 100μs) 650W: 1527W (up to 235% for 100μs) Operating Temperature 50°C Cooling 650W–850W: 120mm FDB Fan 1000W–1200W: 135mm FDB Fan Fan Bearing: Fluid Dynamic Bearing (FDB) Fan Speed: 2400 RPM MTBF 100,000 hours (at full load) Connectors ATX 24 Pin: 1 (all models) EPS 8 Pin: 2 (all models) PCI-E 6 2 Pin: 1200W / 1000W: 8 850W / 750W: 6 650W: 4 Molex 4 Pin: 1200W / 1000W: 3 850W / 750W / 650W: 4 12V-2×6 / 12VHPWR (12 4): 600W: 1200W / 1000W / 850W / 750W: 1 450W: 650W: 1 SATA: 1200W / 1000W: 9 850W / 750W / 650W: 8 Weight 1200W / 1000W Product Cables: 1.77kg 1.28kg With Package: 3.43kg 850W / 750W Product Cables: 1596g 1254g With Package: 3.1kg 650W Product Cables: 1299g 1231g With Package: 2.78kg
