MODEL NAME O11 DYNAMIC EVO MODEL NO. O11DEX BLACK O11DEW WHITE O11DEG GREY COLOR Black White Harbor Grey DIMENSION (D)465mm × (W)285mm × (H)459mm MATERIAL 4mm Aluminum 4mm Tempered Glass 1mm Steel Structure MOTHERBOARD SUPPORT E-ATX (width: under 280mm)/ATX /M-ATX/ITX PSU SUPPORT 220mm FAN SUPPORT Top: 120mm × 3 or 140mm × 2 Side: 120mm × 3 or 140mm × 2 Bottom: 120mm × 3 or 140mm × 2 Rear: 120mm × 1 On Drive Cage: 60mm × 1 RADIATOR SUPPORT Top: 360mm × 1 or 280mm × 1 *Total max thickness: 87.5mm Side: 360mm × 1 or 280mm × 1 *Inner scenario total max thickness: 83mm(120mm fan on top and bottom) 63mm(140mm fan on top and bottom) *Outer scenario total max. thickness： 120mm(120mm fan on top and bottom) 100mm(140mm fan on top and bottom) Bottom: 360mm × 1 *Total max thickness: 87.5mm DRIVE SUPPORT Bottom：2.5” SSD × 4 or 3.5” HDD × 2 Side：2.5” SSD × 4 or 3.5” HDD × 2 Drive Cage：2.5” SSD × 3 or 3.5” HDD × 2 With 2.5” SSD × 1 Cable Management Bar：2.5” SSD × 2 *Only 9 sets of 2.5” SSD mounting pads are provided GPU LENGTH CLEARANCE 426 mm CPU HEIGHT CLEARANCE 167 mm EXPANSION SLOTS 8 I/O PORTS 2 × USB 3.0 1 × USB 3.1 TYPE-C, 1 × HD AUDIO/ MIC LED Color and Mode button Reset Button Power Button DUST FILTER Bottom × 1 WARRANTY 1 year
