CPU Intel® Socket LGA1700 for Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors*Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0**** Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types. Chipset Intel® Z790 Chipset Memory 4 x DIMM slots, max. 192GBDDR5 8000 (OC)/7800 (OC)/7600(OC)/7400(OC)/7200(OC)/7000(OC)/6800(OC)/6600(OC)/6400(OC)/6200(OC)/6000(OC)/5800(OC)/5600/5400/5200/5000/4800 Non-ECC, Un-buffered Memory*Dual Channel Memory ArchitectureSupports Intel® Extreme Memory Profile (XMP) memory moduleSupports DIMM FlexOptiMem IIASUS Enhanced Memory Profile II (AEMP II)* Non-ECC, un-buffered DDR5 memory supports On-Die ECC function. Graphics 1 x DisplayPort**1 x HDMI™ port*** ** Supports max. 8K@60Hz as specified in DisplayPort 1.4.*** Supports 4K@60Hz as specifiead in HDMI 2.1. **** VGA resolution support depends on processors’ or graphic cards’ resolution. Expansion Slots Intel® CoreTM Processors (14th & 13th & 12th Gen)*1 x PCIe 5.0 x16 slot (support x16 mode)** Intel® Z790 Chipset2 x PCIe 4.0 x16 slots (support x4 mode) Storage Supports 5 x M.2 slots and 4 x SATA 6Gb/s ports*Intel® CoreTM Processors (14th & 13th & 12th Gen)M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode)M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode)Intel® Z790 ChipsetM.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_4 slot (Key M), type 2280 (supports PCIe 4.0 x4 mode)M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)4 x SATA 6Gb/s ports* Intel® Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10. Ethernet 1 x Intel® 2.5Gb EthernetASUS LANGuard Wireless & Bluetooth Intel® Wi-Fi 7*2×2 Wi-Fi 7 (802.11be)**Supports 2.4/5/6GHz frequency band***Support Wi-Fi 7 160MHz bandwidth, up to 2.4Gbps transfer rate.Bluetooth® v5.4***** Compatible with Windows 11 or later.** Wi-Fi 7 MLO(Multi-link Operation) full functions support will be ready in Windows 11 2024 Platform (Windows 11 24H2) or later.*** Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries.**** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer’s website for the latest specifications. USB Rear USB (Total 12 ports)1 x USB 20Gbps port (1 x USB Type-C®)11 x USB 10Gbps ports (10 x Type-A 1 x USB Type-C®)Front USB (Total 11 ports)1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD Fast-charge )**2 x USB 5GGps headers support 4 additional USB 5Gbps ports3 x USB 2.0 headers support 6 additional USB 2.0 ports* USB Type-C® power delivery output: max. 5V/3A** USB Type-C® power delivery output: 5V/9V max. 3A, 12V max 2.5A Audio ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080* – Impedance sense for front and rear headphone outputs– Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking– High quality 120 dB SNR stereo playback output and 110 dB SNR recording input– Supports up to 32-Bit/384 kHz playback on front panelAudio Features – SupremeFX Shielding Technology– Savitech SV3H712 AMP – Gold-plated audio jacks – Rear optical S/PDIF out port– Premium audio capacitors– Audio cover* The rear panel Lime (Line out) port does not support spatial audio. If you wish to use spatial audio make sure to connect your audio output device to the audio jack on the front panel of your chassis. Back Panel I/O Ports 1 x USB 20Gbps port (1 x USB Type-C®)11 x USB 10Gbps ports (10 x Type-A 1 x USB Type-C®)1 x DisplayPort1 x HDMI™ port1 x Wi-Fi Module1 x Intel® 2.5Gb Ethernet port5 x Gold-plated audio jacks1 x Optical S/PDIF out port1 x BIOS FlashBack™ button 1 x Clear CMOS button Internal I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header1 x 4-pin CPU OPT Fan header1 x 4-pin AIO Pump header5 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector2 x 8-pin 12V Power connectors Storage related 5 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 20Gbps connector (supports USB Type-C® with up to 30W PD Fast-charge)2 x USB 5Gbps headers support 4 additional USB 5G ports3 x USB 2.0 headers support 6 additional USB 2.0 ports Miscellaneous3 x Addressable Gen 2 headers1 x Alternation PCIe Mode Switch1 x AURA RGB header1 x CPU over voltage jumper1 x Front panel audio header (F_AUDIO)1 x Start button1 x 20-3 pin System Panel header with Chassis intrude function1 x Thermal Sensor header1 x Thunderbolt™ (USB4®) header Special Features Extreme OC Kit– Start button Extreme Engine Digi – 5K Black Metallic CapacitorsASUS Q-Design – M.2 Q-Latch– PCIe Slot Q-Release– Q-Antenna– Q-Code– Q-DIMM– Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green])– Q-Slot ASUS Thermal Solution– M.2 heatsink backplate– M.2 heatsink– VRM heatsink design ASUS EZ DIY– BIOS FlashBack™ button– BIOS FlashBack™ LED– Clear CMOS button– CPU Socket lever protector– ProCool II– Pre-mounted I/O shield– SafeSlot– SafeDIMM AURA Sync– AURA RGB header– Addressable Gen 2 RGB headers Front Panel USB 20Gbps with PD Fast Charge Support– Support: up to 30W fast charging and USB Wattage Watcher– Output: 5V/9V max. 3A, 12V max 2.5A– Compatible with PD3.0 Software Features ROG Exclusive Software– ROG CPU-Z– DTS® Sound Unbound ASUS Exclusive SoftwareArmoury Crate– AIDA64 Extreme (60 days free trial) – Aura Creator– Aura Sync– Fan Xpert 4 (with AI Cooling II)– GameFirst– Power Saving– Sonic Studio– Two-Way AI Noise CancellationAI Suite 3– Easy Optimization with AI Overclocking – TPU– DIGI VRM– Turbo app– PC CleanerMyAsusUSB Wattage WatcherIntel® Unison™Adobe Creative Cloud (Free Trial)Norton 360 for Gamers (60 Days Free Trial)WinRAR (40 Days Free Trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY – ASUS CrashFree BIOS 3 – ASUS EZ Flash 3 – ASUS UEFI BIOS EZ Mode– ASUS MyHotkeyFlexKeyMemTest86 BIOS 256 Mb Flash ROM, UEFI AMI BIOS Manageability WOL by PME, PXE Accessories Cables2 x SATA 6Gb/s cables Additional Cooling Kit1 x Thermal pad for M.2 Miscellaneous1 x ASUS Wi-Fi Q-Antenna 1 x Cable ties package1 x M.2 backplate Q-Latch package1 x M.2 Q-Latch package1 x ROG key chain1 x ROG Strix stickers2 x M.2 Rubber Packages1 x M.2 backplate Rubber Package PackageDocumentation1 x Quick start guide Operating System Windows® 11, Windows® 10 64-bit Form Factor ATX Form Factor12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )
