Chipset AMD X870 CPU Support Compatible with AMD Ryzen™ 9000/8000/7000 Series Desktop Processors Socket: AM5 Memory Capacity: Up to 256GB DDR5 UDIMM (4 slots) Speeds: Overclocking: DDR5 8200 – 5600 MT/s JEDEC: DDR5 5600 – 4800 MT/s Ryzen™ 9000 Series max overclocking: 1DPC 1R: Up to 8200 MT/s 1DPC 2R: Up to 6400 MT/s 2DPC 1R: Up to 6400 MT/s 2DPC 2R: Up to 4800 MT/s Features: AMD EXPOTM support Dual-channel mode Non-ECC, unbuffered memory CUDIMM and manual overclocking supported Note: Compatibility varies by CPU and memory configuration. Refer to the Memory Compatibility List for details. Graphics Integrated Output (CPU Dependent): 1x HDMI™ 2.1 (4K 60Hz) 1x USB4® Type-C DisplayPort 1.4 (4K 60Hz) Expansion Slots PCIe Slots: PCI_E1: PCIe 5.0 x16 (From CPU) PCI_E2: PCIe 3.0 x1 (From Chipset) PCI_E3: PCIe 3.0 x1 (From Chipset) PCI_E4: PCIe 4.0 x4 (From Chipset) Slot bandwidth varies based on the CPU model. Audio Realtek® ALC897 7.1-Channel High Definition Audio Storage M.2 Slots: M.2_1 (PCIe 5.0 x4) for Ryzen™ 9000/7000 Series M.2_2 (PCIe 4.0 x4) from Chipset M.2_3 (PCIe 4.0 x2) from Chipset SATA Ports: 4x SATA 6Gb/s RAID RAID 0 and RAID 1 for M.2 NVMe storage devices USB Connectivity Rear: 4x USB 2.0 2x USB 5Gbps Type-A 2x USB 10Gbps Type-A 1x USB 20Gbps Type-C 1x USB 40Gbps Type-C Front: 4x USB 2.0 2x USB 5Gbps Type-A 1x USB 10Gbps Type-C Network Realtek® 8126VB 5G LAN Wireless LAN & Bluetooth Wi-Fi 7: Pre-installed in M.2 (Key-E) slot 2.4GHz/5GHz/6GHz (up to 5.8Gbps) Bluetooth: Version 5.4 (Windows 11 24H2 ready) Internal I/O 1x ATX Power Connector 2x CPU Power Connectors 6x System Fan Headers 3x Addressable RGB LED Connectors 1x RGB LED Connector LED Features 4x EZ Debug LED
